| TECHNICAL SPECIFICATION |
| Swing Over Bed | 500 mm |
| Std. Turning Dia. | 250 mm |
| Max. Turning Dia. | 320 mm |
| Max. Turning Length | 400 mm |
| X-Axis Travel (Cross) | 175 mm |
| Z-Axis Travel (Longitudinal) | 400 mm |
| Rapid Feed (X & Z Axis) | 24 m/min |
| Spindle Motor Power – Siemens | 9.8 / 7.5 kW |
| Spindle Motor Power – Fanuc | 11 / 7.5 kW |
| Spindle Speed Range | 50-4000 rpm |
| Torque | 55 |
| Spindle Nose | A-5 |
| Max. Bar Capacity | 44 mm |
| Turret | 8 Station |
| Tool Size (Cross Sectional) | 25 x 25 |
| Max. Boring Bar Dia. | 40 mm |
| Quill Dia. | 85 mm |
| Quill Stroke | 120 mm |
| Thrust | 300 Kgf |
| Positioning Uncertainty (P) | 0.007 mm |
| Repeatability (Ps Mean) | 0.005 mm |
| Machine Weight | 3000 Kg |
| Machine Length | 2150 mm |
| Machine Width | 1440 mm |
| Machine Height | 1770 mm |
