| Capacities | No. 3-12” Grinder |
| The Condor | |
| Work Dia. Range | |
| Standard Work rest Low thru feed work rest (optional) | Ø 6 to 120 mm L = 300 mm |
| Grinding Wheel | |
| Dia. x Width x Bore Minimum Dia. Max. Wheel surface speed, (New wheel) Optional Surface Speed | 610 x 508 x 305 mm 432 mm 45 m/sec (9000 sfpm) |
| Regulating Wheel | |
| Dia. x Width x Bore Minimum dia. Speed range | 305 x 305 x 127 mm 229 mm Infinitely variable 10 to 300 rpm |
| Drive Motor | |
| Grd. wheel standard Optional Reg. wheel Hyd. unit | 30 Hp (24 KW) 40 Hp (30 KW), 50 HP (45 KW) 20 Nm 1 Hp (0.75 KW) |
| Coolant Equipment | |
| Tank Capacity Pump Capacity Motor | Optional as required |
| General Data | |
| Floor Space ( L x W x H) | 3200 x 1600 x 1800 mm |
| Approx. Weight of basic grinder. | 7700 kgs |
