| Wheel Size | 558 mm |
| Swing Over Bed | 800 mm |
| Std. Turning Dia. | 560 mm |
| Max. Turning Dia.* | 600 mm |
| Swing over carriage* | 560 mm |
| Slides | |
| X-Axis Travel (Cross) | 360 mm |
| Z-Axis Travel (Longitudinal) | 700 mm |
| Rapid Feed (X & Z Axis) | 20 m/min |
| Main Spindle | |
| Spindle Motor Power -Fanuc | 37/30 kW |
| Spindle Bore | 103 mm |
| Spindle Nose | A2-8 |
| Max. Bar Capacity | – |
| Max. Spindle Speed | 2500 rpm |
| Full Power Speed Range | 766-2300 rpm |
| Tureet | |
| No. of Tools | 12 nos. |
| Max. Boring Bar Capacity | 50 mm |
| Tool Size (Cross Sectional) | 25 x 25 mm |
| Accuracy (As per VDI/DGQ 3441) | |
| Positioning Uncertainty (P) | 0.010 mm |
| Repeatability (Ps medium) | 0.005 mm |
| Other Data | |
| Machine Weight #(Approx.) | 8000 Kg |
| Machine Dimension #(Approx.) | |
| Length | 3030 mm |
| Width | 1970 mm |
| Height | 2025 mm |
