| Max. Turning Lenght* | mm | 625 |
| Std. Turning Dia. (with gripper) | mm | 65 |
| Max. Job Dia.** | mm | 200 |
| Max. Turning Dia.* | mm | 125 |
| Slides | | |
| X-Axis Travel (Cross) | mm | 240 |
| Z-Axis Travel (Longitudinal) | mm | 625 |
| Feed | | |
| Rapid Feed (X/Y/Z Axis) | m/min | 20 |
| Cutting feed | m/min | 10 |
| Main Spindle | | |
| Spindle Speed | rpm | 5000 |
| Spindle Motor Power | kW | 22 |
| Spindle Nose | | A26 |
| C Axis Resolution | Deg. | 0.001° |
| Turret | | |
| No. of Turret [station] | Nos. | 9+9 |
| Tool holder type | | BMT 55 |
| Auto Loader | | |
| Input Feeder | Nos. | 12 |
| Output Feeder | Nos. | 12 |
| Max. Possible Job Weight | kg | 8.5 |
| Accuracy (As per VDI/DGQ 3441) | | |
| Positioning Uncertainty (P) | mm | 0.01 |
| Repeatability (Ps medium) | mm | 0.005 |
| Other | | |
| Machine Weight #(Approx.) | kg | 8700 |
| Machine Dimension # (Approx.) | | |
| Length | mm | 4250 |
| Width | mm | 3050 |
| Height | mm | 3000 |
