| Swing Over Bed | mm | 470 | 470 | 500 |
| Std. Turning Dia. | mm | 100 | 100 | 250 |
| Max. Job Swing Dia.* | mm | 200 | 200 | 365 |
| Max. Turning Length * | mm | 200 | 200 | 500 |
| Slides | | | | |
| X-Axis Travel (Cross) | mm | 360 | 360 | 200 |
| Z-Axis Travel (Longitudinal) | mm | 200 | 200 | 500 |
| Rapid Feed (X & Z Axis) | m/min | 24 | 24 | 24 |
| Main Spindle | | | | |
| Spindle Motor Power -Fanuc | kW | 11/7.5 | 11/7.5 | 11/9 |
| Spindle Motor Power -Siemens | kW | 9.8/7.5 | 9.8/7.5 | 13.5/9 (14.4/11) |
| Spindle Bore | mm | 55 | 55 | 70 (90) |
| Spindle Nose | | A2-5 | A2-5 | A26 (A2-8) |
| Max. Bar Capacity | mm | 44 | 44 | 52 (75) |
| Spindle Speed Range | rpm | 50-4000 | 50-4000 | 50-4000 (3500) |
| Tooling (Gang Type) | | | | |
| Max. Boring Bar Capacity | mm | 40 | 40 | 40 |
| Tool Size (Cross Sectional) | mm | 25 x 25 | 25 x 25 | 25 x 25 |
| Automated Gantry Robot Loader/Unloader | | | | |
| Work piece Dimension (Loader Capacity) | mm | Ø100 x 45 | Ø 105 x 45 | Ø 210 x 100 |
| Max. Part Weight (One Side) | kg | 2.5 | 2.5 | 6 |
| Loader X (Left/Right) Axis Stroke | mm | 1500 | – | – |
| Max. Speed (X Axis) | m/min | 120 | – | 90 |
| Loader Y (Up/Down) Axis Stroke | mm | 560 | – | – |
| Max. Speed (Y Axis) | m/min | 110 | – | 90 |
| Loader Z (Left/Right) Axis Stroke | mm | – | 250 | – |
| Max. Speed (Z Axis) | m/min | – | 50 | – |
| Loader X (Up/Down) Axis Stroke | mm | – | 375 | – |
| Max. Speed (X Axis) | m/min | – | 110 | – |
| Jaw Stroke Per Jaw (Loader Chuck) | mm/deg. | 4 | 6 | 10 |
| Rotation (Swivel Unit) | deg | 90 | – | 90° |
| Tail Stock | | | | |
| Quill Dia. | mm | – | – | 85 |
| Quill Stroke | mm | – | – | 120 |
| Thrust | kgf | – | – | 500 |
| Accuracy (As per VDI/DGQ 3441) | | | | |
| Positioning Uncertainty (P) | mm | 0.007 | 0.007 | 0.007 |
| Repeatability (Ps medium) | mm | 0.005 | 0.005 | 0.005 |
| Other Data | | | | |
| Machine Weight #(Approx.) | Kg | 2900 | 2300 | 4800 |
| Machine Dimension # (Approx.) | | | | |
| Length | mm | 2960 | 3150 | 3700 |
| Width | mm | 1400 | 3000 | 2200 |
| Height | mm | 3080 | 2500 | 3250 |
