| Swing Over Bed | mm | 500 |
| Std. Turning Dia. | mm | 250 |
| Max. Turning Dia.* | mm | 320 |
| Maximum Turning Length * | mm | 320 |
| Slides | | |
| X-Axis Travel (Cross) | mm | 175 |
| Z-Axis Travel (Longitudinal) | mm | 320 |
| Rapid Feed (X & Z axis) | m/min | 24 |
| Main Spindle | | |
| Spindle Motor Power – Siemens | kW | 9.8/7.5 |
| Spindle Motor Power – Fanuc | kW | 11/7.5 |
| Spindle Speed Range | rpm | 50-4000 |
| Spindle Bore | mm | 55 |
| Spindle Nose | | A2-5 |
| Max. Bar Capacity | mm | 44 |
| Turret | | |
| Number of Station | | 8 |
| Max. Boring Bar Dia. | mm | 40 |
| Tool Size (Cross Sectional) | mm | 25 x 25 |
| Tail Stock | | |
| Quill Dia. | mm | 85 |
| Quill Stroke | mm | 120 |
| Thrust (Adjustable) | kgf | 300 |
| Accuracy (As per VDI/DGQ 3441) | | |
| Positioning Uncertainty (P) | mm | 0.007 |
| Repeatability (Ps medium) | mm | 0.005 |
| Other Data | | |
| Machine Weight (Approx.) | kg | 2500 |
| Machine Dimension (Approx.) | | |
| Length | mm | 2163 |
| Width | mm | 1465 |
| Height | mm | 1685 |
