| Chuck Size | mm | Φ210 |
| Workpiece Dimension* | mm | Φ 105*45 |
| Slides | | |
| X1-Axis Travel | mm | 110 |
| Z1-Axis Travel | mm | 200 |
| Rapid Feed (X & Z axis) | m/min | 24 |
| No. Of Tool On X1 | | 1 |
| Slides | | |
| X2-Axis Travel | mm | 110 |
| Z2-Axis Travel | mm | 200 |
| Rapid Feed (X & Z axis) | m/min | 24 |
| No. Of Tool On X2 | | 1 |
| D.Main Spindle | | |
| Spindle Motor Power – Fanuc | kW | 11/9 |
| Spindle Motor Power – Siemens | kW | 14.4/11 |
| Spindle Speed Range | rpm | 50-4000 |
| Spindle Nose | | A2-6 |
| Automated Gantry | | |
| Work piece Dim Capacity of Loader | mm | Ø105 x 45mm (max) |
| Max. Part weight (One side) | kgs | 2.5 |
| W (Front/Rear) Axis Stroke | mm | 255 |
| W (Front/Rear) Axis Max Speed | m/min | 50 |
| V (Up/Down) Axis Max Speed | m/min | 110 |
| Jaw stroke per jaw (Loader Chuck | mm | 6 |
| Accuracy (As per VDI/DGQ 3441) | | |
| Positioning Uncertainty (P) | mm | 0.01 |
| Repeatability (Ps medium) | mm | 0.007 |
| Other Data | | |
| Machine Weight #(Approx.) | kg | 2750 |
| Machine Dimension #(Approx.) | | |
| Length | mm | 1544 |
| Width | mm | 1730 |
| Height | mm | 2600 |
