| Capacity | | | | | | | | | |
| Swing Over Bed | mm | 550 | 550 | 550 | 550 | 650 | 650 | 650 | 650 |
| Std. Turning Dia. | mm | 370 | 330 | 330 | 330 | 465 | 420 | 420 | 420 |
| Max. Turning Dia.* | mm | 370 | 330 | 330 | 330 | 480 | 420 | 420 | 420 |
| Maximum Turning Length * | mm | 325/625 | 325/625 | 325/625 | 625 | 600/1200 | 600/1200 | 600/1200 | 600 |
| Chuck Dia. | mm | 200 | 200 | 200 | 200 | 250 | 250 | 250 | 250 |
| Slides | | | | | | | | | |
| X-Axis Travel | mm | 200 | 200 | 200 | 200 | 250 | 250 | 250 | 250 |
| Y-Axis Travel | mm | NA | NA | ±40 | ±40 | NA | NA | ±50 | ±50 |
| Z-Axis Travel | mm | 325/625 | 325/625 | 325/625 | 625 | 625/1225 | 625/1225 | 625/1225 | 625 |
| Rapid Feed (X,Y & Z- axis) | m/min | 24/NA/30 | 24/NA/30 | 24/24/30 | 24/24/30 | 24/NA/30 | 24/NA/30 | 24/24/30 | 24/24/30 |
| Main Spindle (Motorised) | | | | | | | | | |
| Spindle Motor Power (Cont)Siemens- Fanuc | kW | 9.15 | 9.15 | 9.15 | 9.15 | 20 | 20 | 20 | 20 |
| Spindle Speed Range | rpm | 4500 | 4500 | 4500 | 4500 | 4000 | 4000 | 4000 | 4000 |
| Spindle Nose | | A26 | A26 | A26 | A26 | A28 | A28 | A28 | A28 |
| Max. Bar Capacity | mm | 52 | 52 | 52 | 52 | 65 | 65 | 65 | 65 |
| Sub-Spindle (Motorised) | | | | | | | | | |
| Spindle Motor Power (Cont)Siemens- Fanuc | kW | NA | NA | NA | 7.5 | NA | NA | NA | 9.15 |
| Spindle Speed Range | rpm | NA | NA | NA | 5000 | NA | NA | NA | 4500 |
| Spindle Nose | | NA | NA | NA | A25 | NA | NA | NA | A26 |
| Spindle Travel | mm | NA | NA | NA | 630 | NA | NA | NA | 620 |
| Turret | | | | | | | | | |
| Turret Type | | Servo | Live | Live | Live | Servo | Live | Live | Live |
| Number of Station | | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
| Max. Boring Bar Dia. | mm | 40 | 40 | 40 | 40 | 50 | 50 | 50 | 50 |
| Tool Size (Cross Sectional) | mm | 25 x 25 | 25 x 25 | 25 x 25 | 25 x 25 | 25 x 25 | 25 x 25 | 25 x 25 | 25 x 25 |
| Live Tool Power (Siemens/Fanuc) | kW | NA | 4.8/4.5 | 4.8/4.5 | 4.8/4.5 | NA | 4.8/5.5 | 4.8/5.5 | 4.8/5.5 |
| Live Tool Speed (Siemens) | rpm | NA | 4500 | 4500 | 4500 | NA | 4500 | 4500 | 4500 |
| Live Tool Speed (Fanuc) | rpm | NA | 4500 | 4500 | 4500 | NA | 3000 | 3000 | 3000 |
| Live Tool Type | | NA | VDI30/BMT45 | VDI30/BMT45 | VDI30/BMT45 | NA | VDI40/BMT55 | VDI40/BMT55 | VDI40/BMT55 |
| Tail Stock | | | | | | | | | |
| Tailstock Type | | Digital | Digital | Digital | NA | Digital | Digital | Digital | NA |
| Tailstock Travel | mm | 330/630 | 330/630 | 330/630 | NA | 620/1220 | 620/1220 | 620/1220 | NA |
| Live Quill Taper | | MT-5 | MT-5 | MT-5 | NA | MT-5 | MT-5 | MT-5 | NA |
| Quill Dia. | mm | 130 | 130 | 130 | NA | 130 | 130 | 130 | NA |
| Thrust | kgf | 350 | 350 | 350 | NA | 500 | 500 | 500 | NA |
| Accuracy (As per VDI/DGQ 3441) | | | | | | | | | |
| Positioning Uncertainty (P) | mm | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 |
| Repeatability (Ps medium) | mm | 0.003 | 0.003 | 0.003 | 0.003 | 0.003 | 0.003 | 0.003 | 0.003 |
| Machine Weight # (Approx.) | kg | 4100/4500 | 4200/4600 | 4400/4800 | 5000 | 6300/6900 | 6500/7100 | 6500/7100 | 6700 |
| Machine Dimension # (Approx.) | | | | | | | | | |
| Length | mm | 2610/2910 | 2610/2910 | 2610/2910 | 3220 | 3490/4090 | 3490/4090 | 3490/4090 | 3490 |
| Width | mm | 1735 | 1735 | 1735 | 1735 | 2000 | 2000 | 2000 | 2000 |
| Height | mm | 1960 | 1960 | 1960 | 1960 | 2205 | 2205 | 2205 | 2205 |
