| Spindles | | | |
| No of Spindles | | 2 | 2 |
| Spindle Speed | rpm | 4500 | 4000 |
| Spindle Motor Power (Siemens) | kW | 7.2/5.5 | 13.5/9 |
| Spindle Motor Power (Fanuc) | kW | 7.5/5.5 | 11/9 |
| Spindle Nose | | A2-5 | A2-6 |
| Slide Stroke | | | |
| X-Axis | mm | 75 | 155 |
| Z-Axis | mm | 145 | 162 |
| Rapid Traverse ( X/Z ) | m/min | 24 | 24 |
| Turret | | | |
| No of Turret ( Station ) | | 2[16(8+8)]* | 2[16(8+8)]* |
| Index Time | sec | 0.5 | 0.5 |
| Capacity | | | |
| Chuck Size | mm | Ø 165 | Ø210 |
| Workpiece Dimension (Loader Capacity) | mm | Ø 120*80 | Ø 210*120 |
| | | | |
| Automated Gantry Robot | | | |
| Max Part Weight (No. of Parts) | kg | 3(2) | 6(2) |
| Loader X (left/right) Axis Stroke | mm | 1850 | 2370 |
| Max Speed (X) | m/min | 120 | 120 |
| Loader Y (up/down) Axis Stroke | mm | 560 | 715 |
| Max Speed (Y) | m/min | 90 | 90 |
| Loader Z (front/rear) Axis Stroke | mm | 150 | 250 |
| Max Speed (Z) | m/min | 50 | 50 |
| Std Loading Time | sec | 7 | 9 |
| Accurcy (as per VDI/DGQ 3441) | | | |
| Positioning Uncertainty (P) | mm | 0.007 | 0.007 |
| Repeatability (Ps medium) | mm | 0.005 | 0.005 |
| Other Data | | | |
| Weight (approx) | kg | 4500 | 7500 |
| Machine Dimension (approx) | | | |
| Length | mm | 3000 | 3600 |
| Width | mm | 2250 | 2000 |
| Height | mm | 2750 | 2750 |
